Description:
MY FHTV 3270 is a fluorosilicone silicone compound that is formed by thermal vulcanization after adding a vulcanizing agent (the vulcanizing agent is selected according to the process requirements).
Advantages:
easy to process
Good mechanical properties, high strength and resilience
Excellent oil resistance, solvent resistance and high and low temperature resistance, low dielectric loss of transformer oil
Product technical
data:
ITEM |
index |
|
serial number |
MY FHTV 3270 |
|
Appearance |
Light yellow, translucent |
|
density/ g/cm3 |
ASTM D792 |
1.44 |
hardness/shoreA |
ASTM D2240 |
68 |
Tensile Strength/MPa |
ASTM D412 |
9 |
Elongation at break/% |
ASTM D412 |
265 |
Tear strength/KN/m |
ASTM D624-B |
20 |
compression permanent (177℃*22h ) |
ASTM D395 |
11 |
Resilience/% |
ASTM D1054 |
37 |
*heat resistance 200℃×72h |
Hardness change (Shore A) |
+3 |
Tensile strength change rate,% |
-20 |
|
Elongation at break, % |
-20 |
|
Fuel C volume change rate/%25℃/72h |
ASTM D471 |
+20 |
vulcanization conditions |
Add 0.7 parts of Bi25, first-stage vulcanization: 170℃×15min, second-stage vulcanization: 200℃×4h |
*The data in the table are typical product performance and do not serve as factory standards.
*Meeting heat resistance requirements requires the addition of heat-resistant additives
Processing suggestions:
It is recommended to use 0.6 to 1 part of bis-penta-sulfide curing agent (2,5-dimethyl-2,5-bis(tert-butylperoxy)hexane).
Customers should determine the most appropriate vulcanization temperature and time based on product size and vulcanization method.
Application:
Can be used for molded products, injection molding and extruded tube forming products; has good mechanical properties
Product packaging: 20Kg per box
Storage period:
MY FHTV 3270 should be stored in the original unopened packaging below 40℃ for 12 months from the date of production.
